Features 1, Strong chip with special antenna design
2, Max reading distance up to 4-5 meters reading by CLOU IOT RFID devices
3, Best anti-collision design to help best multi-tag reading
3, Good feedback from clients for successful case
4, Brand,Logo, barcode printing supportable
Parameters Performance Specifications
RFID Chip NXP UCODE 7 Protocol ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 Operating Frequency UHF: 860~960MHz Operating Mode Passive(Battery free) Memory 48 bit Serialized TID, 128 bit EPC, No User Memory IC Life 100,000 Programming cycles, 10 years data retention Read distance Average: 3-5m (Reader and Environment Dependent)
Environment Requirement
Operating Temperature/Humidity -0~60℃ / 20%~80% RH Storage Temperature/Humidity 20~30℃ / 20%~60% RH Shelf Life 1 year in anti-static bag at 20~30℃ / 20% ~60% RH ESD Voltage Immunity 2 kV (HBM) Bending Diameter > 50mm
Delivery Details
Appearance Single row reel form Quantity 3000 ± 10 pcs/Roll;4 Rolls/Carton 440x440x150mm Based on the actual shipment quantity Weight To be determined Final inspection 100 %, known faulty ones marked Delivery yield ≥ 99%
